3 Para Monitor CMS-5100B

₹11,999.00 incl. GST

Monitors three essential parameters: ECG, SpO2, and NIBP
High-resolution display for clear vital sign visualization
Compact, lightweight design for easy portability
Customizable alarm settings for enhanced patient safety
Long-lasting battery for continuous monitoring

TECHNICAL SPECIFICATIONS :

Size: Approx. 165*270*130mm
Weight: Approx. 0.97(kg)
Working environment Temperature: Working temperature – 0-
40(°C) , Transportation and storage temperature – 20~60(°C)
Humidity: Working humidity – ≤85% , Transportation and storage
humidity – ≤93%

Power adapter : Input: 100-240V- 50/60Hz Output: 12VDC 2A
Display information : 2.6 inch 240*320 RESOLUTION
Battery : 2000mAh 3.7V lithium battery
More than 60 minutes working capability
When the low power indicator gives an alarm for the first time, the
patient monitor can still work for 2 minutes.
3 PARA CMS 5100B

NIBP Specification :
MEASURING Method : Pulse wave oscilometry
Work Mode : Manual/Automatic
Measuring Interval of Automatic Measuring Mode :
1,2,3,4,5,10,15,30,00,00,120,180,240,480 minute(s)
Measuring Range and Precision :
Range : Adult
Systolic blood pressure : 40-255 mmHg
Diastolic blood pressure : 10-210 mmHg
Mean blood pressure : 20-230 mmHg
Pediatric
Systolic blood pressure : 40-200 mmHg
Diastolic blood pressure : 10-150 mmHg

Mean blood pressure : 20-165 mmHg
Neonatal baby
Systolic blood pressure : 40-135 mmHg
Diastolic blood pressure : 10-95 MMHG
Mean blood pressure : 20-110 mmhg
Static pressure range : 0-300 mmHg
Static pressure precision : ±3 mmHg
Pressure precision : Max average error: ±5 mmHg: Max standard
deviation: ±8 mmHG
Overvoltage protection :
Adult mode : 300±10 mmHg
pediatric mode : 240±10 mmHg
Neonatal baby mode : 150±10 mmHG
SpO2 Specification :
Sp02
Range : 0~100%
Resolution : 1%
Precision :70-100% ±4% DIGIT
0%~69%: no definition given
PR
Range : 30-240bpm
Resolution : 1bpm
Precision : ±3bpm
PI
Range : 0%~20%, Measurement
error is not defined
Resolution : 0.1%

TEMP Specification :
Suitable for temperature sensor : Temperature probe, body cavity
probe
Channel quantity : 1 channels
Measuring :
Range : 20~45°C°C
Resolution : 0.1°C
Precision : ±0.2°C (excluding sensor error)

Other :
At most 1 waveforms display
One alarm indicator(yellow/red)
One working indicator(green)
One battery charge state indicator(green)

Compare

Categories: Home Medical Supplies & Equipment, Patient Monitors, Personal Care Tags: 3ParaMonitor, BloodPressureMonitor, CMS5100B, ECGMonitor, HealthMonitoringSystem, HeartRateMonitor, HospitalEquipment, MedicalEquipment, PatientMonitoring, VitalSignsMonitor

Description
Reviews (0)

Description

The Dr. Diaz CMS-5100 B 3-Parameter Monitor is a versatile and reliable device designed for accurate and efficient patient monitoring. It measures three essential parameters: ECG, SpO2, and non-invasive blood pressure (NIBP), providing comprehensive and real-time vital sign monitoring. The compact and lightweight design makes it suitable for use in various healthcare environments, including hospitals, clinics, and home care settings. The high-resolution display ensures clear visualization of vital data, allowing healthcare professionals to make prompt and informed decisions. With user-friendly controls and customizable alarm settings, the CMS-5100 B offers enhanced operational efficiency and patient safety. Its long-lasting battery supports continuous monitoring, ensuring uninterrupted care.
